NC40U
NC40U
FORM FACTOR: Shuttle 0.85L Form Factor PROCESSOR: Intel® 12th Gen Celeron 7305 15W CPU i3-1215U, i5-1235U, i7-1255U (optional) MEMORY: 2 x 260 pin DDR4 SODIMM slots, 32GB per DIMM (Max 64GB) Dual Channel DDR4 ,up to 3200Mhz AUDIO: C-Media CM6542 ETHERNET: Built in Intel I219 support 10/100/1000Mbs DRIVE BAYSL: (1)2.5" 15mm SATA HDD / SSD DIMENSIONS: 142(L) x 142(W) x 42(H) mm POWER: 65 Watts (19V/3.42A)

Product Specification

FORM FACTOR: Shuttle 0.85L Form Factor PROCESSOR: Intel® 12th Gen Celeron 7305 15W CPU i3-1215U, i5-1235U, i7-1255U (optional) MEMORY: 2 x 260 pin DDR4 SODIMM slots, 32GB per DIMM (Max 64GB) Dual Channel DDR4 ,up to 3200Mhz VIDEO OUTPUT: Integrated Intel® Iris Xe graphics (features depend on processor) 1x HDMI 2.0b Port + 2x DisplayPort Triple video outputs AUDIO: C-Media CM6542 ETHERNET: Built in Intel I219 support 10/100/1000Mbs STORAGE INTERFACE: SATA 6.0Gb/s interface NVMe interface Support SATA RAID 0,1 Support NVMe RAID 0,1 DRIVE BAYSL: (1)2.5" 15mm SATA HDD / SSD DIMENSIONS: 142(L) x 142(W) x 42(H) mm POWER: 65 Watts (19V/3.42A) EXPANSION SLOT: (1)M.2 2230 E key (1)M.2 2280 M key(w/PCIe Gen3 x 4, SATA 6 Gb/s) (1)M.2 2280 M key(w/PCIe Gen4 x 4) OS SUPPORT: Windows 11 Linux ACCESSORIES: Quickguide DVD driver VESA mount Foot Stand Adapter and power cord screw pack
